Max. lifting height
2850
Driving motor
10
Lifting frame horizontal & machine straight
950
Own weight
2200
Technical drawing
- (A) Overall length with bin
- 4080
- (B) Overall length without bin
- 3079
- (C) Bin pivot
- 550
- (D) Cradle base
- 1480
- (E) Rear overhang
- 948
- (F) Height to top of roof
- 2200
- (H) Seat height
- 1190
- (J) Total working height
- 3465
- (K) Max. lifting height
- 2850
- (L) Loading height
- 2686
- (M) Ejection height
- 2135
- (N) Range (m)
- 529
- (O) Digging depth
- 17
- (P) Overall width
- 1104
- (Q) Track width
- 803
- (S) Ground clearance
- 178
- (T) Outer diameter
- 2646
- (U) Turning circle
- 2928
- (V) Inside turning circle
- 1503
- (W) Rotation angle
- 45
- (X) Tilting angle at max. lifting height
- 59
- (Y) Tipping angle
- 39
- (Z) Tilt-in angle
- 50
Specifications
Electric motor
- Driving motor
- 10
- Running time
- 6 uur
Hydraulic system
- Oil yield
- 30
- Workload
- 170 bar
Weight
- Lifting frame horizontal & machine straight
- 950
- Lifting frame horizontal & machine tilted
- 600 kg
- Max. Lifting capacity
- 1250
- Own weight
- 2200
