Max. lifting height
3000
Max. Lifting capacity
1800
Own weight
3490
Technical drawing
- (A) Length to spoon plate
- 1915
- (B) Height to top of roof
- 2040
- (C) Overall width
- 1130
- (D) Front track width
- 960
- (E) Rear track width
- 178
- (F) Cradle base
- 1360
- (G) Max. lifting height
- 3000
- (H) Mast height low
- 2200
- (I) Ground clearance
- 100
- (J) Front overhang
- 380
Specifications
Dimensions
- Turning circle
- 1540
Electric motor
- Driving motor
- 6.5
Weight
- Max. Lifting capacity
- 1800
- Own weight
- 3490
